WATROMAT® Sludge Dryer

WATROMAT^® batch sludge dryer uses dried air to reduce the weight and volume of filter cake sludge. Sludge drying with WATROMAT^® batch sludge dryers is ideal for filter cake sludge from small and medium plate and frame filter presses. The filter cake sludge is filled into WATROMAT^® drying containers and will be dried with dry air. All WATROMAT^®drying containers have integrated tipping systems. Sludge drying with WATROMAT^® standard sludge dryer is maintenance-poor and emission-free.

Features and benefits

Dry 60 – 4000 kg sludge/day
Needs min. 30 % dried solids
Use 0.33 kWh power per kg separated water
Reach 90 % dried solids

Technical Specifications

Standard Specifications

Model	50S	100S	200S	400S	600S	800S	1200S	1600S	2000S	2400S
Evaporative capacity (water)
kg/day	50	100	200	400	600	800	1200	1600	2000	2400
lbs/day	110	220	440	880	1320	1760	2640	3520	4400	5280
Energy power
kW (50 Hz)	1,6	2,6	4,6	7,9	9,9	12,6	20	26	32	39
kW (60 Hz)	1,9	3,1	5,5	9,5	12	15	24	31	38	47
Dimensions dry air generator in mm/inch
Length	670/26	670/26	980/38	980/38	980/38	980/38	1290/50	1290/50	1600/62.4	1600/62.4
Width	980/38	980/38	1290/50	1290/50	1910/75	1910/75	2675/104	2675/104	3900/152	3900/152
Height	1440/56	1440/56	2035/79	2035/79	2035/79	2035/79	2035/79	2035/79	2035/79	2035/79
Dimensions drying container in mm/inch
Length	925/36	1125/44	1325/52	1325/52	1325/52	1325/52	2340/91	2340/91	2340/91	2340/91
Width	780/30	980/34	1180/46	1680/66	1680/66	2180/85	2230/87	2230/87	2230/87	2230/87
Height	750/29	1054/41	1054/41	1154/45	1154/45	1154/45	1210/47	1210/47	1470/56	1470/56
Storage volume drying container
Litre	180	500	770	1320	1320	1700	2700	2700	3700	3700
Cubic foot	7	18	28	47	47	61	96	96	132	132

Disclaimer: We continuously update and improve our products and services, contact us for more detailed information or to confirm specifications. MAK Water takes no responsibility for any errors resulting from the use of information contained on this website.
