Packaged Sewage Pump Station

MAK Water’s Packaged Sewage Pump Stations (PSPS) are designed to receive raw domestic strength sewage into a below ground collection tank. The raw sewage is macerated to ≤ 2mm particle size, before discharging to a wastewater treatment plant for treatment. The standard package includes a polyethylene tank with access cover and all required PVC pipework, valves and fittings, dual macerator pumps, lifting chains and guide rails, dual pump controller and float level switches.

A range of common flow rates and tank sizes are provided to suit most wastewater applications. Optional equipment upgrades are available, including tank and access cover materials and a valve chamber; if required.

 STANDARD SPECIFICATIONS

Parameter Units PSPS-01 PSPS-02 PSPS-03 PSPS-04 PSPS-06 PSPS-09
Pump flow rate*1 L/s 1 2 3 4.5 6 9
Pump discharge pressure*1 mH2O 18 12.5 14.8 22 18.8 20.5
Tank capacity (nominal) L 1,200 / 1,800 / 2,780 / 3,150
Tank dimensions (approx.) mm 1,200L: Ø1,100 x 1,665(h)
1,800L: Ø1,400 x 1,530(h)
2,780L: Ø1,400 x 2,150(h)
3,150L: Ø1,400 x 2,400(h)
Tank (and optional valve chamber) access cover Class A Pedestrian traffic, nominal load 330 kg
Class B*2 Occasional light vehicle traffic, nominal load 2,670 kg
Class D*2 Slow moving commercial vehicle traffic, nominal load 8,000 kg
Raw sewage inlet  - Domestic strength
Macerated sewage outlet - ≤ 2mm particle size
Ambient design temperature °C max. 60
Power supply  - AC 415 V, 3 Phase, 50 Hz
Control panel IP rating - IP56 (higher IP rating available on request)
Pump motor (each) kW 1.1 1.1 1.7 4.4 4.4 7.4

*1Nominal flow/pressure, refer to pump curve for duty specific sizing *2Requires concrete support slab

STANDARD INCLUSIONS + OPTIONS

✓= Standard Supply o = Optional Supply

Equipment PSPS-01 PSPS-02 PSPS-03 PSPS-04 PSPS-06 PSPS-09
Duel macerator wastewater pumps ✓ ✓ ✓ ✓ ✓ ✓
Discharge pipework (PVC, Class 12) with isolation and check valve for each pump ✓ ✓ ✓ ✓ ✓ ✓
Guide rails, lifting chains, nuts and bolts in SS316  ✓ ✓ ✓ ✓ ✓ ✓
Tank materials PE ✓ ✓ ✓ ✓ ✓ ✓
Custom (e.g. FRP, concrete) o o o o o o
Tank access cover Class A ✓ ✓ ✓ ✓ ✓ ✓
Class B o o o o o o
Class D o o o o o o
Valve chamber  With class A access cover o o o o o o
With class B access cover o o o o o o
With class D access cover o o o o o o

Control panel in powder coated mild steel, with inner door and removable gland plate

 Mains isolator and individual pump isolation ✓ ✓ ✓ ✓ ✓ ✓
Circuit breaker protected low voltage control and input circuitry ✓ ✓ ✓ ✓ ✓ ✓
Contactor and thermal overload protection of pumps ✓ ✓ ✓ ✓ ✓ ✓
Electronic short and overload protection of strobe/buzzer ✓ ✓ ✓ ✓ ✓ ✓
Visual and audible alarm, with mute/reset/test button ✓ ✓ ✓ ✓ ✓ ✓
Keypad with indicator lights for power on, level alarm, pump run/fault ✓ ✓ ✓ ✓ ✓ ✓
Auto/off/manual operation of pumps ✓ ✓ ✓ ✓ ✓ ✓
Maximum run timer and auto alternation of pump duty ✓ ✓ ✓ ✓ ✓ ✓
Volt free output (VFC) for common fault ✓ ✓ ✓ ✓ ✓ ✓
Additional VFC output card (for high/low level & pump run signals) o o o o o o
Mounting post (HDG)  o o o o o o



Instrumentation Included
Level control float tree Level switch - start ✓
Level switch - stop ✓
Level switch – high alarm ✓
Level switch – low alarm ✓
